The EC motor is a conventional permanent magnet synchronous motor that needs an external variable frequency drive (VFD) to operate, with a maximum power of 30 kW. The ECI motor features a built-in variable frequency drive (VFD), with a maximum power of 5 kW.
· EC motors reach the IE5+ energy efficiency level (the highest international energy efficiency standard as of June 2026), with an efficiency of 90% to 96%.
· Even with an integrated drive, ECI motors still meet the EU IE5 energy efficiency standard, which is equivalent to China's Class 1 Energy Efficiency.
Livestock ventilation fans, indoor and outdoor fans for central air conditioners, cabinet cooling fans, air purification and fresh air units, cold storage fans, data center cooling systems, industrial fans, water pumps, dust removal equipment, as well as energy-saving renovation of traditional AC motors.
· EC Motor: Star (Y) connection: 100~1800 rpm; Delta (△) connection: 300~3600 rpm
· ECI Motor: 100~900 rpm / 300~1500 rpm / 600~4000 rpm
If the required rotating speed is beyond the above ranges, please consult our sales or pre-sales technical staff for confirmation in advance.
· EC motor: Standard IP55, upgradable to IP66.
· ECI motor: The T-ECI series comes with standard IP55 and can be upgraded to IP66; the F-ECI series is standard IP66 and upgradable to IP67.
Both EC and ECI motors support variable frequency speed regulation. Standard products adopt three control modes: 0-10V VSP, PWM and Modbus RS485.
Our products are sold to Europe, North America, South America, Australia and other regions, with CE and ETL as the main certifications.
We provide OEM processing services for renowned enterprises in the industry. Full product customization is available, and customized service is one of our core commitments.
· For use within China: 12 months starting from the date customers receive the products.
· For overseas use: 18 months calculated from the product shipment date.
Our products support all IEC standard motor mounting types, including B3, B30, B14, B5, B34, B35, B14B and B5R.
We are able to provide 2D and 3D drawings for installation.
The standard applicable ambient temperature ranges from -25℃ to 40℃. Standard products may not work properly under extreme temperature conditions. Please contact our sales or technical team to select matched customized models.
